• material: aluminium
  • 24" wheelsize
  • 135x9mm axle standard
  • BSA bottom bracket standard
frame size 11.5"
color TEAL (DARK TEAL)
  • Coil
  • 50mm suspension travel
derailleur (r) Shimano RD-M310
brake lever Alloy Junior
shifter rear MRX Comp Twist Shifter
brake front V-Brake Linear
brake rear V-Brake Linear
chain KMC M700
crank size 152 mm
  • 100x9mm width front hub
  • 24 spoke holes
  • 135x9mm width rear hub
  • 24 spoke holes
  • material: aluminium
  • 11-34 teeth
  • 8 speed
spokes Black steel
  • material: aluminium
  • 31.8mm diameter
  • -6° stem angle
  • 60 mm
  • material: aluminium
  • 620mm width
  • 20mm rise
headset FSA TH888
  • material: aluminium
  • 27.2mm diameter
  • 15mm setback
kickstand center type alloy
weight 12 kg
Bike Frame Geometry Image
Frame Size 11.5"
Tire Sizes 24"
Frame Size Inch 11.5
Frame Size CM 29
ST seat tube [mm] 289
TT top tube [mm] 505
CS chain stay length [mm] 410
HTA head tube angle [°] 69
STA seat tube angle [°] 72
BD bottom bracked drop [mm] 29
HT head tube [mm] 120
FL fork length [mm] 390
R reach [mm] 345
S stack [mm] 492
WB wheel base [mm] 999
SH stand over height [mm] Boy:515/Girl:474
Body Height Cm 130 - 150

Technologies


RACELITE 61 ALUMINIUM

We use a minimum of 6061 aluminium. The pay back is that it’s possible to make lighter and more advanced frames. We use an additional heat treatment and double-butted wall thicknesses to produce light and stiff frames.


F-MOUNT

‘F-Mount’ equipped bikes have integrated fittings for mud guards (some bikes require model specific mud guards), making fitting fast and simple.


K-MOUNT

Integrated mount on the chainstay to fit a MERIDA kickstand (or any commercial kickstand).


C-MOUNT

‘C-Mount’ equipped bikes have the fixing points for a rear rack already integrated (some bikes require model specific rear rack), making fitting fast, simple and reliable.
