• material: aluminium
  • 24" wheelsize
  • 135x9mm axle standard
  • BSA bottom bracket standard
frame size 11.5"
color PINK (BARBIE BLUE/GREY)
  • Coil
  • 50mm suspension travel
derailleur (r) Shimano RD-M310
brake lever Alloy Junior
shifter rear MRX Comp Twist Shifter
brake front V-Brake Linear
brake rear V-Brake Linear
chain KMC M700
crank size 152 mm
  • 100x9mm width front hub
  • 24 spoke holes
  • 135x9mm width rear hub
  • 24 spoke holes
  • material: aluminium
  • 11-34 teeth
  • 8 speed
spokes Black steel
  • material: aluminium
  • 31.8mm diameter
  • -6° stem angle
  • 60 mm
  • material: aluminium
  • 620mm width
  • 20mm rise
headset FSA TH888
  • material: aluminium
  • 27.2mm diameter
  • 15mm setback
kickstand center type alloy
weight 12 kg
Bike Frame Geometry Image
Frame Size 11.5"
Tire Sizes 24"
Frame Size Inch 11.5
Frame Size CM 29
ST seat tube [mm] 289
TT top tube [mm] 505
CS chain stay length [mm] 410
HTA head tube angle [°] 69
STA seat tube angle [°] 72
BD bottom bracked drop [mm] 29
HT head tube [mm] 120
FL fork length [mm] 390
R reach [mm] 345
S stack [mm] 492
WB wheel base [mm] 999
SH stand over height [mm] Boy:515/Girl:474
Body Height Cm 130 - 150

CATEGORY HIGHLIGHTS

Durable aluminium frame. For 24" and 20" wheels with replaceable dropout hanger and equipped with mounts for rack, mudguards and kickstand. 16" or 12" wheel options are optimised for the use with training wheels.

Our new MATTS J+ bikes feature not just a new and weight optimised frame but are also designed around 20" or 24" 'plus' tyres for extra grip and comfort, without adding unnecessary weight. Simple, stylish and hugely effective.

The specific demands on childrens' components make them differ a lot from adult components. Not only that kids are smaller, but also do not have the same strength in their hands for example when it comes to braking. That's why we have chosen specific components to ensure that our youngest cyclists are able to use their bikes safely and comfortably and make them easy to handle in any situation.

Many of our bikes feature rigid forks. This helps to keep the weight down, which is a big advantage for much lighter riders. Gears are also kept to a minimum, avoiding confusion for young riders, again reducing weight.

All kids’ bike frames are made with the same 6061 lightweight aluminium we use in our adult bikes, we don’t cut any corners. They’re also painted and lacquered in the same way, so the bikes can still look great even after a few tough knocks.

Technologies


RACELITE 61 ALUMINIUM

We use a minimum of 6061 aluminium. The pay back is that it’s possible to make lighter and more advanced frames. We use an additional heat treatment and double-butted wall thicknesses to produce light and stiff frames.


F-MOUNT

‘F-Mount’ equipped bikes have integrated fittings for mud guards (some bikes require model specific mud guards), making fitting fast and simple.


K-MOUNT

Integrated mount on the chainstay to fit a MERIDA kickstand (or any commercial kickstand).


C-MOUNT

‘C-Mount’ equipped bikes have the fixing points for a rear rack already integrated (some bikes require model specific rear rack), making fitting fast, simple and reliable.
