brakes V-Brake Linear / Shimano ST-EF500
frame JULIET SPEED -V
frame size XS, S, M, L
fork Suntour M3010; Coil, 63 STR
color TEAL (BLUE/BLACK)
derailleur (f) Shimano TZ30
derailleur (r) Shimano RD-TX35
rotors N/A
shifter front Shimano Revo RS-35
shifter rear Shimano Revo RS-35
brake front V-Brake Linear
brake rear Shimano ST-EF500
chain KMC Z7
crank Shimano TY301; 42-34-24 ATC
hub front Alloy QR
hub rear Alloy QR
rim Merida double V
freewheel Shimano MF-TZ21; 14-28 ATC; 7 spd
tyre front MERIDA K1047; 26x2.1"; wire
tyre rear MERIDA K1047; 26x2.1"; wire
spokes Black steel
handlebar stem A-Head OS dia-cast
handlebar VP; VPE-891
headset A-Head OS
seat post MERIDA speed 27.2
saddle MERIDA Juliet Sport
Frame Size | XS | S | M | L |
Tyre Sizes | 27.5" | 27.5" | 27.5" | 27.5" |
ST seat tube [mm] | 343 | 381 | 432 | 470 |
TT top tube [mm] | 536 | 546 | 561 | 571 |
CS chain stay length [mm] | 430 | 430 | 430 | 430 |
HTA head tube angle [°] | 69.5 | 69.5 | 70 | 70 |
STA seat tube angle [°] | 74.5 | 74.5 | 74.5 | 74.5 |
BD bottom bracket drop [mm] | 65 | 65 | 65 | 65 |
HT head tube [mm] | 95 | 100 | 110 | 120 |
FL fork length [mm] | 493 | 493 | 493 | 493 |
R reach [mm] | 372 | 380 | 392 | 399 |
S stack [mm] | 602 | 607 | 618 | 628 |
WB wheel base [mm] | 1039 | 1050 | 1060 | 1071 |
SH stand over height [mm] | 582 | 612 | 664 | 694 |
Body Height Cm | < 163 | 157 - 173 | 167 - 183 | > 177 |
