- material: aluminium
- 27.5x2.25" max. wheelsize
- 135x9mm axle standard
- BSA bottom bracket standard
- Smooth welding
frame size XS, S, M, L
color MATT BLUE (WHITE)
- Air
- 100mm suspension travel
- Lockout
- 42mm fork offset
- 27.5x2.25" max. wheelsize
- 2 piston
- 180mm
- 160mm
headset MERIDA M2346 Neck
grip MERIDA COMP EC
shifters Shimano Deore M4100
- material: aluminium
- 30.9mm diameter
- 0mm setback
seat clamp MERIDA COMP QR
saddle MERIDA COMP CC
pedal VP VPE-891
chain KMC X10
- 32 teeth
- 170 mm-S, 175 mm-M up
crank 170 mm-S, 175 mm-M up
- 11-46 teeth
- 10 speed
- 100x9mm width front hub
- 32 spoke holes
- Centerlock
- 135x9mm width rear hub
- 32 spoke holes
- Centerlock
- 20mm inner width
- material: aluminium
- 27.5x2.2"
- wire
- 27.5x2.2"
- wire
spokes Black stainless
weighed with 27.5" wheels and at frame size M, without pedals
max. weight 135 kg
Frame Size | XS | S | M | L |
Tyre Sizes | 27.5" | 27.5" | 27.5" | 27.5" |
ST seat tube [mm] | 340 | 380 | 440 | 480 |
TT top tube [mm] | 550 | 570 | 590 | 610 |
CS chain stay length [mm] | 430 | 430 | 430 | 430 |
HTA head tube angle [°] | 69 | 69 | 69 | 69 |
STA seat tube angle [°] | 73 | 73 | 73 | 73 |
BD bottom bracket drop [mm] | 30 | 30 | 30 | 30 |
HT head tube [mm] | 100 | 115 | 130 | 145 |
FL fork length [mm] | 487 | 487 | 487 | 487 |
R reach [mm] | 378 | 394 | 409 | 425 |
S stack [mm] | 563 | 577 | 591 | 605 |
WB wheel base [mm] | 1056 | 1078 | 1099 | 1120 |
SH stand over height [mm] | 649 | 689 | 740 | 778 |
