brakes Shimano ST-EF505

        frame JULIET SPEED

        frame size XS, S, M, L

        fork SR Suntour XCM HLO Coil 100 STR Lockout

        color silver (teal)

        shock no

        derailleur (f) Shimano FD-TY700

        derailleur (r) Shimano RD-M360

        shifter front Shimano ST-EF505

        brake lever Shimano ST-EF505

        brake front Shimano ST-EF505

        chainwheel Shimano TY301 42-34-24 ATC

        chain KMC M700

        hub front Shimano TX505 100x9 WHF 32 SPH Centerlock

        hub rear Shimano TX505 135x9 WHR 32 SPH Centerlock

        rim MERIDA CC 17 IWR

        freewheel Sunrace CSM668 11-32 ATC 8 spd

        tyre front MERIDA K1080 27.5x2.1" wire

        tyre rear MERIDA K1080 27.5x2.1" wire

        spokes Black steel

        handlebar MERIDA CC 660 WHB 25 RHB

        headset FSA NO.10P Neck15

        seat post MERIDA CC 27.2 DSP 15 SSB

        saddle MERIDA Juliet Sport

| Frame Size | XS | S | M | L |
| Tyre Sizes | 27.5" | 27.5" | 27.5" | 27.5" |
| ST seat tube [mm] | 343 | 381 | 432 | 470 |
| TT top tube [mm] | 536 | 546 | 561 | 571 |
| CS chain stay length [mm] | 430 | 430 | 430 | 430 |
| HTA head tube angle [°] | 69.5 | 69.5 | 70 | 70 |
| STA seat tube angle [°] | 74.5 | 74.5 | 74.5 | 74.5 |
| BD bottom bracket drop [mm] | 65 | 65 | 65 | 65 |
| HT head tube [mm] | 95 | 100 | 110 | 120 |
| FL fork length [mm] | 493 | 493 | 493 | 493 |
| R reach [mm] | 372 | 380 | 392 | 399 |
| S stack [mm] | 602 | 607 | 618 | 628 |
| WB wheel base [mm] | 1039 | 1050 | 1060 | 1071 |
| SH stand over height [mm] | 582 | 612 | 664 | 694 |
| Body Height Cm | < 163 | 157 - 173 | 167 - 183 | > 177 |
