• material: aluminium
  • 700x32C max. wheelsize
  • 100x9/135x9mm axle standard
  • BSA bottom bracket standard
frame size XS, S/M, L, XL
fork Speeder Rigid Steel
  • 17mm inner width
  • material: aluminium
  • 100x9mm width front hub
  • 32 spoke holes
  • centerlock
  • 135x9mm width rear hub
  • 32 spoke holes
  • centerlock
  • 48-38-28 teeth
  • 170mm - XXS/SM, 175mm - ML/XXL length crank
crank size 170mm - XXS/SM, 175mm - ML/XXL length crank
bottom bracket FSA TH-7420ST-W, Cartridge Bearing
  • 11-32 teeth
  • 8 speed
chain Sunrace M84
shifters Shimano ST-EF505
front derailleur Shimano FD-TY710
rear derailleur Shimano RD-M360
brake lever Shimano BR-MT200
  • BR-MT200 brake caliper
headset FSA NO.10P
  • material: aluminium
  • 31.8mm diameter
  • 100mm on all sizes
stem size 100mm on all sizes
  • material: aluminium
  • 600mm width
  • Flat
grip MERIDA EC
  • material: aluminium
  • 27.2mm diameter
  • 15mm setback
saddle MERIDA D1-072
pedal VP, VPE-891

weighed with 700C wheels and at frame size S-M, without pedals

Bike Frame Geometry Image
Frame Size XS S/M L XL
Tyre Sizes 28" 28" 28" 28"

HIGHLIGHTS

Since its redesign for the 2020 season, the SPEEDER has become more sporty. By increasing the length of the top tube, we have achieved a slightly longer reach, which offers the rider a more sportive riding position while still being on the comfortable side. Furthermore, this geometry change leads to a longer wheelbase, which has a positive effect on directional stability and in combination with the slightly slacker head tube angle, improves the riding stability at speed.
