- material: aluminium
- 700x50C (with fender) max. wheelsize
- 135x9mm axle standard
- internal
- max. 630 Wh
Rammestørrelse XS, S, M, L, XL
Farge WHITE (BLACK)
- Coil
- 63mm suspension travel
- 700x52C max wheelsize
- 2 piston
- 2 piston
Styrelager MERIDA CAP w/ wire gateway
Holker / styretape MERIDA EXPERT TK
Bakre girhendel Shimano Alivio M3100
- 30.9mm diameter
- 15mm setback
- 40mm seatpost suspension travel
Sadelklemme MERIDA EXPERT
- V-mount
Pedal VP VPE-891
Kjede KMC e9S
Kjedefører MTK700 SP40
- 38 teeth
- Shimano FC-E6100
Kjedekasse Sunnywheel SW-CG-173A
- 170 mm
- 11-36 teeth
- 9 speed
- 20mm inner width
- material: aluminium
- 622-50
- wire
- reflecting line
- 622-50
- wire
- reflecting line
- 100x9mm width front hub
- 32 spoke holes
- Centerlock
- 135x9mm width rear hub
- 36 spoke holes
- Centerlock
Skjermer Sunnywheel SW-FA311-60E1 (MSB)
Eiker Black stainless
lys Herrmans H-Black MR4 E / Spanninga Commuter Glow XE integrated in MERIDA MIK HD carrier
bagasjebrett MERIDA MIK HD Carrier with Spring clip & Spanninga rear light
støtte Atranvelo 1219-PC-7
- 60Nm
- 504Wh
batterilås Abus Key
display Shimano SC-E5000
- 2A charging current
rammelås Abus 4650 XL
Bremsestrømpe VLD-880 Foam Black
weighed with 700C wheels and at frame size S, without pedals
max vekt 150 kg
manual MERIDA
| Rammestørrelse | XS | S | M | L | XL |
| Dekkstørrelse | 28" | 28" | 28" | 28" | 28" |
| ST - Seat Tubes (mm) | 380 | 430 | 480 | 530 | 580 |
| TT - Top Tube (mm) | 580 | 595 | 615 | 635 | 655 |
| CS - Chain Stays (mm) | 470 | 470 | 470 | 470 | 470 |
| HTA - Head Tube Angles (°) | 70 | 70 | 70 | 70 | 70 |
| STA - Seat Tube Angle (°) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| BD - Bottom Bracket Drops (mm) | 65 | 65 | 65 | 65 | 65 |
| HT - Head Tube Length (mm) | 170 | 175 | 180 | 190 | 200 |
| FL - Fork Length (mm) | 475 | 475 | 475 | 475 | 475 |
| R - Reach (mm) | 386 | 399 | 418 | 435 | 452 |
| S - Stack (mm) | 656 | 661 | 665 | 675 | 684 |
| WB - Wheel Base (mm) | 1113 | 1128 | 1149 | 1169 | 1190 |
| SH - Stand Over Height (mm) | 413 | 413 | 412 | 412 | 411 |
